344

PAGING SOLUTIONS

View our searchable electronic catalog at: www.jenne.com • 800-422-6191

Paging system enHanCements

V-9927A

V-9936A

V-9945A

V-9983-W

In-Wall Main Control Module

• ContemporaryStylingto

 MatchToday’sOffices,

 ConferenceRooms

 andRestaurantEnvironments

• AMasterVolumeControl

 isProvidedfor

 Fine-LevelAdjustments

• An8-SegmentLEDMeter

 ProvidesInstantVisualIndication

 ofAudioSignalLevels

• TheBuildingPageInputOverrides

 AllOtherSources(voice-operated,switch-enabled)

• Full-FrequencyRangeOutputforSpeakersand

 ModifiedOutputforHornLoads

• Built-InCompressor(optionswitchcontrolled)

 EvensOutLoudandQuietInputs

JENNE PART NUMBER:

V-9983-W

V-9984-W

Remote Input Module

• XLRMic.ConnectionwithReleaseButton,

 ProvidingaSecureConnection

• PhantomPower(switchcontrolled)with“ON”

 IndicatorAllowstheUseof

 ProfessionalCondenserMicrophones

• StereoMini-JackforAuxiliarySources,

 SuchasMP3andCDandDVDPlayers,as

 WellasComputerSoundCards

• ConnectstoMainControlModulewith

 2-Pair24AWGStationCable

• ScrewTerminalsforEasyConnection

 toDistributionCable

JENNE PART NUMBER:

V-9984-W

V-9985-W

In-Wall Mixer

• ContemporaryStylingtoMatchToday’sOffices,Conference

 RoomsandRestaurantEnvironments

• AMasterVolumeControlisProvidedforFinalLevelAdjustments

• An8SegmentLEDMeterProvidesInstantVisualIndicationof

 AudioSignalLevels

• TheBuildingPageInputOverridesAllOtherSources

 (voice-operated,switch-enabled)

• FullFrequencyRangeOutputforSpeakersandModifiedOutput

 forHornLoads

• Built-inCompressor(optionswitchcontrolled)EvensOutLoud

 andQuietInputs

• Operateson24VdcRequiring1ValcomPowerUnit

JENNE PART NUMBER:

V-9985-W

V-9927A

Multi-Tone Generator

• RingingoverPagingSystem

• Upto8DifferentToneswithaSingleUnit:

-Siren-Evacuation

-Whoop-Tornado

-Warble-Fire

-Steady-ShiftChanges

-Burst-AlarmSignal

-Telebell-AuxiliaryRing

-Chime-Doorbutton/CodeCall

-DualChime-DoorbellRing

• InputImpedance:600ohm;

 OutputImpedance:8ohm;

 PowerRequirements:-24Vdc,65mA

JENNE PART NUMBER:

V-9927A

POWERUNIT:-2

V-9945A

Loud Ringer Horn

• InterruptedorUninterrupted

 ContactClosureActivation

• Built-inToneGenerator,5-Watt

 AmplifierandVolumeControl

• WarbleTone-NightRing

• SingleTone-TimeClock/

 Doorbell/Alarm

• SingleToneOverridesWarbleTone

 ifActivatedSimultaneously

• Input:ContactClosureActivation;

 PowerRequirements:-24Vdc

JENNE PART NUMBER:

V-9945A

POWERINCLUDED

V-9936A

Six-Line Audible Ring Unit

• RingingoverPagingSystem

• 90-VacRingorDry-Contact

 ClosureActivation

• Integrateswithupto6COLinesorPBX

 StationLines

• ContactClosuretoActivateLoudBells,

 Accommodates6LinesEach-4UnitsCan

 BeConnectedTogetherforupto24Lines

• Built-inWarbleToneGenerator,Interrupter,

 VolumeControlandPunchdownBlock

• OutputImpedance:8ohm;

 PowerRequirements:-24Vdc,

 200mAPowerSupply

JENNE PART NUMBER:

V-9936A

POWERUNIT:-4
