338

PAGING SOLUTIONS

View our searchable electronic catalog at: www.jenne.com • 800-422-6191

Paging PoWer suPPly

VP-6124

VP-412A

VPB-6124-UPS

VP-624D

· 0.6Amp/24V

· BarrelPlug&BarrelPlugto

 WireAdapter

· ShippingWeight:0.36lb(0.16kg)

· Dimensions:

 1.40”Hx1.50”Wx3.60“L

 (3.56cmx3.81cmx9.14cm)

JENNE PART NUMBER:

VP-624D

POWERUNIT:+12

VP-1124D

· 1Amp/24V

· BarrelPlug&BarrelPlugto

 WireAdapter

· ShippingWeight:0.38lb(0.17kg)

·

Dimensions:1.20”Hx1.80“Wx4.10”L

 (3.05cmx4.57cmx10.41cm)

JENNE PART NUMBER:

VP-1124D

POWERUNIT:+20

VP-2124D

· 2Amp/24V

· BarrelPlug&BarrelPlug

 toWireAdapter

· ShippingWeight:0.75lb(0.34kg)

· Dimensions:1.30”Hx2.0”Wx4.80”L

 (3.30cmx5.08cmx12.19cm)

JENNE PART NUMBER:

VP-2124D

POWERUNIT:+40

VP-4124D

· 4Amp/24V

· BarrelPlug,LowEnergyScrew

 TerminalConnectingBlock

· ShippingWeight:1.14lbs(0.51kg)

· Dimensions:1.50”Hx2.60”Wx6.80”L

 (3.81cmx6.60cmx17.27cm)

JENNE PART NUMBER:

VP-4124D

POWERUNIT:+80

VP-412A

400 mA Unfiltered Receptacle Mount

Special Purpose Power Supply

• Usedwithalimitednumberofspecificproducts

• ForusewithV-2952FMTuner

 andV-9970StationLevelPage

• UL,CSAListed

• DCOutput:-12Vdc,400mA

• PowerRequirements:

 120Vac,1A,11W

• ShippingWeight:3.1lbs.(1.41kg)

• Dimensions:2.6”Hx2.0”Wx2.3”D

 (6.6cmx5.08cmx5.84cm)

JENNE PART NUMBER:

VP-412A

POWERUNIT:N/A

VP-2148D

· 2Amp/48V

· BarrelPlug&BarrelPlugto

 WireAdapter

· ShippingWeight:1.14lbs(0.51kg)

· Dimensions:1.50”Hx2.60”Wx6.80”L

 (3.81cmx6.60cmx17.27cm)

JENNE PART NUMBER:

VP-2148D

POWERUNIT:N/A

VP-6124

6-A Wall Mount, -24 Vdc

Switching Power Supply

• DCOutput:-24Vdc,6A

• PowerRequirements:120Vac/1.7A;165W

• ShippingWeight:7.1lbs.(3.22kg)

• Dimensions:11.50”Hx6.13”Wx2.63”D

 (26.16cmx15.04cmx6.35cm)*

• ALSOAVAILABLEIN12AMP

JENNE PART NUMBER:

VP-6124

*IncludesHardwareCord

POWERUNIT:+120

VP-624D

VP-1124D

VP-2124D

VP-4124D

VP-2148D

VP-6124-UPS

Battery Back-Up Charger for VP-6124

• GiveyourVP-6124theAdvantageofUPS

• CablesIncludedforConnectiontothe

 VP-6124andVBB-1424(BatteryBox)

• WallMount

• ChargingVoltage27.6,VoltsCurrent:900mA

• ShippingWeight:4.0lbs.(1.82kg)

• Dimensions:10.3”Hx3.5”Wx2.25”D

 (26.16cmx8.89cmx5.72cm)

JENNE PART NUMBER:

VP-6124-UPS

POWERUNIT:N/A

VBB-1424

Battery Box with Batteries

• CompleteyourUPSSystemwithBattery

 Support(ForusewithVP-6124/VP-6124-UPS)

• Provides14AH/-24VGelCellStoragewhen

 usedwiththeVP-6124-UPSPowerSystem

• WallMount•14AH@-24Vdc

• ShippingWeight:40lbs.(18.2kg)

• Dimensions:5.52”Hx8.03”Wx10.82”D

 (14.02cmx20.4cmx27.48cm)

JENNE PART NUMBER:

VBB-1424

POWERUNIT:N/A
