328

PAGING SOLUTIONS

View our searchable electronic catalog at: www.jenne.com • 800-422-6191

Paging Controls

V-2926

Option Card for V-2924A Talkback Intercom System

• ProvidesEnhancementFeaturesfortheV-2924A,Flexible

 ArchitecturalNumberPlan

• EasyPlug-InforRemoteLaptopProgramming•PC-Compatible

 ProgrammingPortwithWindows®-BasedProgrammingTool

• EnhancedCallerID,Real-TimeInternalClockforPrinterOutput,

 SecondarySerialPort,User-DefinedPageGroups

• ComputerRequirements:Hardware:80486(orhigheris

 recommended);HardDrivewith20MbytesFree;Mouse,8Mbytes

 ofRAM(moreisrecommended);Software:MSWindows®95,

 MSWindows®98andMSWindows®NT

JENNE PART NUMBER:

V-2926

V-2928

V-2971

Call Switch with Volume Control

• UsewiththeV-2924A,ExpandableTalkback

 IntercomSystem

• CallButtonProvidesQuickConnectiontoa

 DesignatedStation

• FitsaSingle-GangElectricalBox

• Black“Call”ButtonforNormalCall

JENNE PART NUMBER:

V-2971

V-CLK2924

Clock Connection Kit

EnhancestheV-2924AbyAddingSchedulingCapabilityforClassand

ShiftChangeTonesandMasterClockControlforSynchWireClock

TheV-CLK2924IncludesaV-2928OptionCard,andaV-2927/V-CIO

ClockControlRelayInterface

JENNE PART NUMBER:

V-CLK2924

Paging Controls V2924a add-ons

V-2925A

V-2924A

Expandable Talkback Intercom System

• 24StationsofHandsfreeIntercomwithOne-WayGroupCallandAll-Call

• Upto3ExpansionUnitsMaybeConnectedtoProvide48,72or96ZonesofPaging

 withHandsfreeReply,upto16One-WayPageGroupsandAll-Call

• RiotMode•AllCall/GroupCall/EmergencyOverrideAllCall

• BackgroundMusicInput•DoorUnlockControl•ToneInputs

• SMDRPrinterPorts•”MeetMe/FollowMe”•CallerID•ClassofService/Zone

• IntegrateswithPage-Port,PABXLoop-StartTrunkPort,Electronicor1A2LineKey(linecardrequired)

 orDedicatedSingleLinePhoneSet

• InputImpedance:600ohm;MusicSourceImpedance:10Kohms;MusicInputLevel:-10dBmNominal;Output

 Level:45ohm;PowerRequirements:120/240Vac,1.5Amp,50/60Hz

JENNE PART NUMBER:

V-2924A

POWERUNIT:0

V-2927

Clock Control Card for use with V-2928 Option Card

• ProvidesClockControlforSynchWireCorrection,Two-WireDigital

 CorrectionandWirelessCorrectionWhenUsedwithAdditional

 Equipment

JENNE PART NUMBER:

V-2927A

POWERUNIT:0

V-2928

Option Board for V-2924A with

Time-Event Scheduler

• TheV-2928HasAlltheFeaturesof

 theV-2926PlusTime-Event

 SchedulingSoftware

• DistributeWork/ClassChangeTones

 throughPagingSpeakerGroups

 UsingInternalClock

• GenerateAutomatedVoice-Paging

 AnnouncementswithOptionalMessageUnit

JENNE PART NUMBER:

V-2928

POWERUNIT:0

V-CIO

Clock Relay Card for use with V-2928 Option Card

• ProvidesFour10AmpContactRelaysforDrivingClocks

• DesignedforUsewiththeV-2927

JENNE PART NUMBER:

V-CIO

POWERUNIT:0

V-2925A

Add-on Expansion Unit

• 24-ZoneincrementfortheV-2924ATalkback

 PagingIntercomSystem

• UptoThree(3)V-2925AExpansionUnitsCanBe

 AddedtoaMainV-2924ASystemforaMax.

 Configof96Zones

JENNE PART NUMBER:

V-2925A

POWERUNIT:0
