343

Paging SOLUTiOnS

Every effort has been made to ensure the integrity of this catalog. Jenne, Inc. cannot be held responsible for any misrepresentation associated with any products due to

omissions, typographic errors or misprints.

Paging system enHanCements

V-9989

Multi-Messenger USB Digital Message Repeater

Valcom’sMulti-MessagerUSBIsaSolid-StateDigitalMessage

RepeaterthatStoresMessagesinMP3FormatonIndustryStandard

USBFlashDrives.TheMessagesCanbeAssignedContinuousPlay,

TimedPlaywithaBuilt-inTimerCircuitorTriggeredontheEight

InputstheUnitProvides.

• 8InputsForTriggeredMessages•TriggeredAnd/OrTimed

 Playback

• PlaysMP3FilesFromUSBFlashDrive

• UpTo4GBFlashDrivesSupported

• NoDriversOrSpecialSoftwareNeeded

• Auxiliary12VdcOutputForWiringSensors

• PlaybackQualityUpTo128Kbps

• ActiveOutputIndicationTrigger

• Built-inMonitorSpeaker

• LEDStatusIndicator

JENNE PART NUMBER:

V-9989

V-9992

Digital Sound-Level Meter Pro II

• ProfessionalInstrumentation

• Compact,NewlyDesignedShape

• High-Tech,High-Performance

• EasyMax/MinFunctions

• 32to130dB/3Ranges

• A/CWeighting

• Resolution0.1dB

• IEC651TypeII

• PowerRequirement:One9-Volt

 Battery,006PorIEC6F22

 orNEDA1604(BatteryIncluded)

JENNE PART NUMBER:

V-9992

VMT-1

Input/Line Matching Transformer

DesignedtoMatchInputsfromorOutputstoa600ohmLine.Used

asanInput-MatchingTransformer,itConnectsTelephoneSystems

toMostPublicAddressAmplifiers,forTelephonePaging.Italso

FunctionsasanOutput-MatchingTransformertoFeedProgram

MaterialOvera600ohmTelephoneLinefor“Music-on-Hold”.

CompatiblewithanyAmplifierHavinga25VOutputConnection.

• Hi-Z,10KohmPrimaryImpedance

• Lo-Z,600ohmSecondaryImpedance,BalancedwithCenterTap

• MatchesHigh-to-LoworLow-to-HighImpedance

• AdaptsLine-LevelSignals

 toMicrophoneInputs

• PhonoJackonScrewTerminals

 forHi-ZSide

• ScrewTerminalsforLo-ZSide

• SteelEnclosurew/MountingEars

 AllowsEasyMounting

JENNE PART NUMBER:

VMT-1

V-9923B

V-9924C

V-9925A

POWERUNIT:N/A

V-9923B

Signal Code Call Unit

• ForSecurity/Priority-aToneMay

 BeBetterthanaVoice

• UseinHospitals-whenVoice

 AnnouncementsareNotWanted

• UseinDepartmentStores-Does

 NotDistractCustomers

• SendsTonesthroughPaging

 SpeakersorActivatesBellsfrom

 aContactClosure

• Upto81Two-DigitCodesor729

 Three-DigitCodes,“MeetMe”

 AnswerthroughAnalogPBXStation,

 AcceptsPulseDialandToneDial

• InputImpedance:600ohm;

 PowerRequirements:-24Vdc,

 300mAFilteredBattery

JENNE PART NUMBER:

V-9923B

POWERUNIT:-6

V-9924C

CO Audible Ringer

• RingingoverPagingSystem

• 90-VacRing,18-VacorDryContactClosure

 Activation

• IntegrateswithAnalogPBXStationPort

• Provides3SeparateZoneOutputsand

 VolumeControls(forusewithone-way

 ortalkbackpagecontrols)

• AutomaticallyInterruptsPage

 orMusicDuringRinging

• PowerRequirements:-24Vdc,300mA

 (90Vacor18Vactoactivate)

JENNE PART NUMBER:

V-9924C

POWERUNIT:-6

V-9925A

Loud Warble Horn

• 90-VacRingor18-VacBuzzerVoltageActivation

• IntegrateswithPBXorStationLines

• Built-inToneGenerator,5-WattAmplifierandVolumeControl

• PowerRequirements:-24Vdc,500mA:Activatewith90Vac,

 18Vac

JENNE PART NUMBER:

V-9925A

POWERUNIT:-10
